It can be deployed as a PlayStation 5 application or used as a standalone orchestration component. The project handles the application packaging workflow, embeds ELF payloads directly into the generated orchestrator.elf, and provides a local HTTP control plane for managing their execution order.

You can place the required application assets, dependencies, and payloads under the app/ directory and let the build system handle the packaging and embedding process. Payloads can then be registered dynamically, assigned individual delays, and executed sequentially through a simple HTTP API.

The number of embedded payloads is configurable, allowing a single orchestrator.elf to carry an entire payload chain rather than requiring a separate ELF delivery mechanism for each stage.

The service is intentionally bound to the loopback interface and designed to operate as a short-lived orchestration layer rather than a persistent daemon.

Key Features

PlayStation 5 application packaging and installation workflow
Build-time embedding of multiple ELF payloads into a single orchestrator.elf
Configurable payload capacity
Dynamic task queue management
Ordered payload execution with per-task delays
Process lifecycle management and SceShellUI lifecycle synchronization
Thread-safe producer/consumer communication
Loopback-only HTTP control plane
Graceful self-termination after sequence completion

Architecture

sce-hell0 consists of a small HTTP server built on libmicrohttpd and a payload chain orchestrator running within the same ELF binary.

The orchestrator manages multiple independent ELF payloads and executes them in a defined order. Each task may specify an execution delay, while the sequence controller can coordinate execution around the lifecycle of SceShellUI.

Client (HTML/JS)
  │
  │ HTTP (loopback)
  ▼
┌────────────────────────────────────────────────────────┐
│ on_request() router                                    │
│   ├── /add_task          ──► task_queue[] (mutex)      │
│   ├── /clear_tasks                                     │
│   └── /trigger_sequence  ──► pthread_create(...)       │
└────────────────────────────────────────────────────────┘
  │
  ▼
┌────────────────────────────────────────────────────────┐
│ sequence_thread()                                      │
│   1. Copy the queue                                    │
│   2. Restart ShellUI                                   │
│   3. Wait for restoration                              │
│   4. Execute payloads sequentially                     │
│   5. Self-terminate                                    │
└────────────────────────────────────────────────────────┘

At build time, payloads are collected from /app/payloads and embedded directly into orchestrator.elf. At runtime, the orchestrator exposes them through the task queue and executes them according to the requested sequence.

Usage and Directory Structure

You can compile the service as an application or, if you prefer, run only the orchestration layer on your PlayStation 5 device.

The entire automation chain required to develop a WebKit autoloader is provided by sce-hell0. However, if you want to automate the execution process of the orchestration payload, you should know that you must host a kernel exploit chain under the /app folder. Then, in the final stage of this chain, you need to spawn an elfldr.elf at the kernel level, create a TCP socket to communicate with this payload, and spawn the orchestrator.elf file with a simple function on the specified port. For an example chain, check out the arg0WAK/WAK1360-Relapse repository.

Client-Side and JavaScript API Usage

Once the orchestration service is running, you can communicate with the local HTTP API (default: http://127.0.0.1:11110) via index.html. The structure provided under the app folder offers ready-to-use JavaScript helpers (helper.js) for you to manage your payload sequence.

`helper.js`

To streamline your frontend development process, helper.js provides the following functions:

log(msg, status): Creates colored log entries on the screen (info, warning, success, error). Ideal for tracking process steps.
sleep(ms): Defines an asynchronous wait (delay) time.
fetchWithTimeout(url, ms, options): Sends HTTP requests (fetch) with timeout support to prevent potential hangs.
checkFileExists(fileUrl): Checks whether the specified file (e.g., orchestrator.elf) is accessible.

Example Workflow (`/app/index.html`)

Project Structure and Configuration Guidelines

main.c Configuration: Before compiling, you must edit the main.c file in the source code according to your project. Set the TITLE_ID for your application, and if you are using a different ELF Loader, update the ELFLDR_PORT (default: 9021) according to the port of your loader.
orchestrator.c Configuration: The maximum number of tasks (payloads) the orchestrator.elf file can hold is determined by the MAX_TASKS constant found in the orchestrator.c source code. The default value is 10. If your chain requires more than 10 payloads, you must increase this value before compiling.
Application Icon (assets/icon0.png): To customize the application icon, you can replace the icon0.png file under this folder with your own custom icon.
/install: Only your installer interface, index.html, should reside in this folder. You can reference the existing index.html in this folder for your personal development processes.
/app: Only the dependencies of the application to be installed should be placed in this folder.

*IMPORTANT: Please do not edit the cache.appcache file located under this folder; it is managed by the build and caching mechanism. Define the directories you want to exclude during compilation under the static const char *const excluded[] = { variable located in main.c.

/app/payloads: Host your .elf files expected to be included in the generated orchestrator.elf file here. Note: The contents of this folder are not kept in the AppCache during the build process; they are solely embedded directly into the orchestrator.elf file.

# Test builds
┌────────────────────────────────────────────────────────┐
│ /app/payloads                                          │
│   ├── sce-hell0-payload-1.elf                          │
│   ├── sce-hell0-payload-2.elf                          │
│   ├── sce-hell0-payload-3.elf                          │
│   ├── sce-hell0-payload-4.elf                          │
│   └── sce-hell0-payload-5.elf                          │
└────────────────────────────────────────────────────────┘

Build Instructions

To compile the project, you must have the ps5-payload-dev/sdk installed and configured in your environment. You can install it to the SDK path specified in the Makefile or update the file according to your preference.

SDK    := /opt/ps5-payload-sdk

To compile along with an installer, use the following command:

make clean && make

Once the build process is complete, you need to send the resulting installer.elf file to your PS5 device over the network (e.g., using Netcat) to trigger the installer.

nc <PS5_IP> <ELFLDR_PORT> < installer.elf

If you only need the orchestration payload, you can use the orchestrator.elf file located under the /install/payloads folder after a successful build.

API Endpoints

Endpoint	Method	Description
`/add_task?name=&delay=`	GET	Adds a new task to the queue.
`/clear_tasks`	GET	Clears the queue, including leftover tasks from a previous execution.
`/trigger_sequence`	GET	Starts executing the queued tasks sequentially.

Technical Details

Concurrency Model

The server runs with MHD_USE_INTERNAL_POLLING_THREAD and 2 worker threads.
task_queue and task_count are protected by the task_lock mutex.
The kill_pending atomic flag ensures that only one sequence can run at a time using atomic_exchange.
As soon as sequence_thread starts, it copies the queue and clears the original; this prevents an interrupted execution from leaving the queue in an inconsistent state.

Dependencies

ps5-payload-dev/sdk
karlson2k/libmicrohttpd (Vendored static library on Unofficial Mirror)

Scope

sce-hell0 is intended for homebrew development and authorized research on user-owned or explicitly authorized systems.

The authors are not responsible for misuse or operation outside authorized environments.

No physical disc copies were harmed during the development of this project.

No discs were required, either.
